PRICE INCLUDES $2500 REBATE
Overview
- Condition: New vehicle
- Manufacturer: Honda
- Model: PIONEER 1000 5-P TRAIL
- Year: 2025
- Stock #: A10011
- Type: Side-by-side
- Exterior colour: Green
- Engine Capacity: 999.0 CC
- Cylinders: 2
- Transmission: Automatic
- Drivetrain: 2WD/4WD
- Cooling system: Liquid cooling
- Speed: 6
Specifications
- Engine Type: Liquid-cooled longitudinally mounted parallel-twin cylinder
- Displacement: 999 cc
- Bore & Stroke: 92 mm x 75.1 mm
- Compression Ratio: 10.0:1
- Valve Train: Unicam, 4 valves
- Fuel Delivery: PGM-FI electronic fuel injection with 44 mm throttle body
- Transmission: Fully automatic, Six-speed plus Reverse Dual Clutch Transmission with Sport Mode and Manual Mode with Paddle Shifting. High/Low Range Sub-transmission. Three drive modes include Turf, 2WD, i-4WD.
- Power Steering: Standard
- Final Drive: Direct front and rear driveshafts
- Front Suspension: Independent Double A-arm with FOX QS3 (Quick Switch – 3 position) hydraulic shocks; 268 mm (10.6 in) travel
- Rear Suspension: Independent Double A-arm with adjustable FOX QS3 hydraulic shocks; 254 mm (10 in) travel
- Tires: Front: 27 x 9 - 14 Rear: 27 x 11 - 14
- Brakes: Front: Dual 210 mm discs Rear: Dual 210 mm discs
- Towing Capacity: 1,134 kg (2,500 lb)
- Bed Capacity: 454 kg (1,000 lb)
- Length: 3,095 mm (121.9 in)
- Width: 1,599 mm (63 in)
- Height: 1,940 mm (76.4 in)
- Ground Clearance: 313 mm (12.3 in)
- Wheelbase: 2,038 mm (80.2 in)
- Curb Weight: 812 kg (1,790 lb)
- Fuel Capacity: 30.0 liters, including 6.4-liter reserve
- Colour: Mat Infantry Green Metallic
- Warranty: 12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus
Notes
Notes:
Pioneer 1000-5P Trail Looking for a 999 cc side-by-side that matches power, performance and durability? It’s time to get to know the Honda Pioneer 1000-5P Trail edition. Additional Features QuickFlipTM seatsExperience ultimate flexibility in seating options. In addition to the comfortable three passenger contoured bench seat up front, the bed incorporates a pair of QuickFlipTM seats that flip up or fold down independently in seconds. Up, they provide secure seating for one or two additional passengers; down, you get a flat cargo bed for utility use.
Powerful TowingYou can load a full half-ton (1,000 lb.) into the bed. And when it’s time to unload, the bed’s hydraulic-assisted tilting feature makes dumping firewood, gravel, feed or other items easy. And because it’s able to tow a full ton (more than 2,500 lb.) – with a hitch mount – the Pioneer 1000’s can take on big jobs that otherwise would require a tractor or a truck.
Secure DesignThe Occupant Protection Structure uses large-diameter tubing and includes integrated handholds, recessed top tubes and a more spacious structure to enhance protection. Hard doors and roll-up side nets provide a secure feel and keep mud and debris out of the cabin, while automotive-style three-point belts with an Emergency Locking Retractor mechanism help keep everyone secure.
LCD Instrument DisplayThe instrument display is easy to read, with big and bright graphics. The display includes a clutch indicator and a battery-voltage readout too, in addition to speed, fuel level, RPM, transmission mode, water temperature, trip information and more.
Prewired for AccessoriesAll Pioneer 1000 models are pre-wired for accessory switches, so you don’t have to run a lot of extra wiring. For things like a winch alone, it slashes installation time as well as making the installation easier and cleaner. We’ve even included an extra, integrated grounding terminal.
Accessory Switch PanelStandard equipment on the Pioneer 1000, the switch panel has room for seven switches, letting you control things like a winch, accessory lights, and more. A fully integrated design, it sits in the center of the dashboard, underneath the other switches and controls.
Warn WinchThis is a huge upgrade and standard equipment on our Pioneer 1000-5 Forest and Trail models. The winch is installed at the factory, and is built right into the Pioneer’s chassis, not added on as an accessory. With a 4500-pound capacity and spooled with steel cable, you’ll be ready to pull your buddy out when he gets stuck!
Trail EditionThe Pioneer 1000-5P Trail is equiped to take on any two-track adventure with it's standard winch, a 12V outlet in the bed, rearview mirror, interior lights, cup holders and underseat/underdash storage.
