Specifications
- Manufacturer: Arctic Cat
- Model: Jag 400 Sno Pro SG White
- Year: 2027
- Type: Trail
- Engine Type: 400, 2-Stroke
- Displacement: 397cc
- Cooling: Liquid
- Cylinders: 1
- Bore x Stroke: 85 x 70 mm
- Lubrication: Electronic Injection
- Ignition: Digitally Controlled CDI
- Engine Stator Output: 270W @ 3000 RPM
- Fuel Delivery: Electronic Fuel Injected (EFI)
- Exhaust: APV with Tuned Pipe, Pipe Sensor, Manifold & Stainless Steel Muffler
- Fuel Capacity: 11.7 gal
- Oil System Capacity: 3.25 qt
- Coolant System Capacity: 4.6 qt
- Minimum Octane: 91
- Drive Clutch: CVTech Trailbloc
- Driven Clutch: CVTech Invance
- Drive System: Arctic Drive System
- Brakes: Stealth Hydraulic Master Cylinder
- Clutch Calibration: 0-5,000 ft
- Gearing: 19/50
- Chain Pitch: 90
- Track Drive Sprocket: 8 Tooth, 2.86 Pitch, Involute
- Reverse: Push-Button Engine
- Front Suspension: Arctic Mountain Suspension (AMS)
- Ski Shocks: AC5S
- Sway Bar: N/A
- Front Travel: 7.2 in
- Rear Suspension: SLIDE-ACTION with 3 wheel rear axle assembly and adjustable torsion springs
- Front Track Shock: AC5S
- Rear Track Shock: AC5S
- Rear Travel: 13.5
- Overall Chassis Length: 115 in
- Overall Chassis Width: 46-47 in
- Overall Chassis Height: 45 in
- Track Type: Ripsaw
- Track Width: 15
- Track Length: 129 in
- Lug: 1.25 in
- Pitch: 2.86 in
- Ski Stance: 39.5-40.5 in - Adjustable
- Ski Type/Width: Trail - 6 in
- Runner Type: Twin Split
- Type of Gauge: Standard
- Speedometer: Digital
- Tachometer: Digital
- Odometer: Digital
- Fuel: Digital
- Oil: Indicator Light
- Coolant: Indicator Light
- Clock: N/A
- Battery Voltage: N/A
- Altimeter: N/A
- Hours: Digital
- Color: White
- Heat Exchanger: Front Long Tunnel
- Starter: Turnkey Electric Start
- Handlebars: Hooked
- Lighting: Halogen 1-Bulb
- Seating: Mid-Size
- Standard Accessories: Hand & Thumb Warmers, Standard Brake Disc, Standard Steering, Tether Switch
- Windshield: 15.5 in High/4 in Low
