Price:
$16,574
Overview
- Condition: New vehicle
- Manufacturer: Yamaha
- Model: GRIZZLY EPS
- Year: 2026
- Stock #: A9695
- Type: ATV (Quad)
- Exterior colour: CAMO
- Engine: 4 stroke
- Engine Capacity: 686.0 CC
- Transmission: CVT
- Drivetrain: 2WD/4WD
- Cooling system: Liquid cooling
- Weight: 701.00 lbs
- Length: 6.80 ft
- Width: 4.00 ft
- Speed: P / R / N / H / L
Specifications
- Engine: Liquid-cooled, SOHC 4-stroke
- Displacement: 686cc
- Bore and Stroke: 102 mm x 84 mm
- Compression Ratio: 10 : 1
- Fuel Delivery: Yamaha Fuel Injection (YFI), 44 mm
- Ignition: TCI
- Starting: Electric
- Lubrication: Wet sump
- Transmission: Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P
- Final Drive: On-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft
- Suspension (Front): Independent double wishbone; 5-way preload adjustment / 193 mm (7.6") of wheel travel
- Suspension (Rear): Independent double wishbone with anti-sway bar; 5-way preload adjustment / 232 mm (9.1") of wheel travel
- Brakes (Front): Dual hydraulic disc
- Brakes (Rear): Dual hydraulic disc
- Tires (Front): AT26 x 8-12 Maxxis® MU05Y
- Tires (Rear): AT26 x 10-12 Maxxis® MU06Y
- Length: 2070 mm (81.5")
- Width: 1230 mm (48.4")
- Height: 1253 mm (49.3")
- Wheelbase: 1250 mm (49.2")
- Maximum Ground Clearance: 288 mm (11.3")
- Turn Radius: 3708 mm (146")
- Tread (Front): 1000 mm (39.4")
- Tread (Rear): 975 mm (38.4")
- Seat Height: 918 mm (36.1")
- Wet Weight: 318 kg (701 lb)
- Fuel Capacity: 18 L
- Rack Capacity (Front): 50 kg (110 lb)
- Rack Capacity (Rear): 90 kg (198 lb)
- Towing Capacity: 600 kg (1,322 lb)
- Warranty: One year (unlimited mileage) / 10 Year Belt Warranty
Notes
Notes:
TRAIL TESTED, RIDER APPROVED. With superior capability, all‑day comfort and legendary durability, the Grizzly is the best-performing ATV in its class.
KEY FEATURES
- Powerful 686cc engine
- Speed-sensitive electric power steering (EPS)
- On-Command® four-wheel drive system
- High Performance Ultramatic® Transmission
- Long Travel Shocks with wide-arc A-arms
- Full-body skid plates
- 2,500 lb Warn® VRX winch
- 14-inch aluminum wheels wrapped in 27-inch Maxxis® Zilla tires
- High-quality camo bodywork
