Price:
$13,674
Overview
- Condition: New vehicle
- Manufacturer: Yamaha
- Model: KODIAK 700
- Year: 2026
- Stock #: A9693
- Type: ATV (Quad)
- Exterior colour: Green
- Engine: 4 stroke
- Engine Capacity: 686.0 CC
- Drivetrain: 2WD/4WD
- Cooling system: Liquid cooling
- Seats: 1
- Weight: 686.00 lbs
- Length: 6.80 ft
- Width: 3.90 ft
- Speed: P / R / N / H / L
Specifications
- Engine: Liquid-cooled, SOHC 4-stroke
- Displacement: 686cc
- Bore and Stroke: 102 mm x 84 mm
- Compression Ratio: 10 : 1
- Fuel Delivery: Yamaha Fuel Injection (YFI), 44 mm
- Ignition: TCI
- Starting: Electric
- Lubrication: Wet sump
- Transmission: Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P
- Final Drive: On-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft
- Suspension (Front): Independent double wishbone; 5-way preload adjustment / 180 mm (7.1") of wheel travel
- Suspension (Rear): Adjustable independent double wishbone with anti-sway bar; 5-way preload adjustment / 232 mm (9.1") of wheel travel
- Brakes (Front): Dual hydraulic disc
- Brakes (Rear): Multi-Disc wet brake
- Tires (Front): Maxxis MU19, AT25 x 8-12
- Tires (Rear): Maxxis MU20, AT25 x 10-12
- Length: 2070 mm (81.5")
- Width: 1180 mm (46.5")
- Height: 1240 mm (48.8")
- Wheelbase: 1250 mm (49.2")
- Maximum Ground Clearance: 274 mm (10.8")
- Turn Radius: 3200 mm (126")
- Tread (Front): 940 mm (37")
- Tread (Rear): 915 mm (36")
- Seat Height: 860 mm (33.9")
- Wet Weight: 311 kg (686 lb)
- Fuel Capacity: 18 L
- Rack Capacity (Front): 50 kg (110 lb)
- Rack Capacity (Rear): 90 kg (198 lb)
- Towing Capacity: 600 kg (1,322 lb)
- Colour(s): Tactical Green
- Warranty: One year (unlimited mileage) / 10 Year Belt Warranty
Notes
Notes:
BEARING DOWN. Devouring chores with comfort and confidence, this rugged and reliable machine makes light of tough work.
KEY FEATURES
- Powerful 686cc engine
- Speed-sensitive electric power steering (EPS)
- On-Command® four-wheel drive system
- High Performance Ultramatic® Transmission
- Wide-arc A-arms
- Full-length composite skid plates
- 12-inch aluminum wheels wrapped in 25-inch Maxxis® tires
